The electric machine laboratory is located in the south zone of the ground floor of the building of the School of Industrial Engineering, with access through the door 0.530.L. It occupies an approximate surface of 180 m2 and is mainly dedicated to the subjects taught in the third and fourth year of the degree programs as well as master subjects. In its facilities, the teaching practices related to the testing of electrical transformation, generation and traction machines of different technology are developed. Likewise, this unit and its material are also used in the studies carried out by the research groups in their work.

This laboratory consists of a total of 9 stands with a capacity of up to 4 students per stand. Each stand consists of the following instrumentation:

  • Voltmeters
  • Ammeters
  • Single and three phase wattmeters
  • Phase meters
  • Adjustable DC power supply
  • Oscilloscope
  • Set of capacitors, inductances and resistors
  • Set of switches and push buttons
  • Variable resistance rheostat
  • Single-phase and three-phase transformers
  • Asynchronous and synchronous machines
  • Tachoelectric dynamo
  • Torque meter
